Unyielding Power and Precision

The Resilient Sounds GOLD V2 18" is engineered for the serious audio enthusiast seeking massive, accurate bass from a conservatively rated power platform. The V2 generation brings significant upgrades, including a larger, heavily-vented triple-stack 220mm motor and an extended 3-inch 4-layer voice coil, which contribute to its impressive 31mm of XMAX. Built on a robust cast aluminum frame, the GOLD V2 is designed for longevity and peak performance. The Dual 4 Ohm voice coil allows for flexible wiring options, achieving a final load of 2 Ohms or 8 Ohms to match a wide range of mono amplifiers.



TECHNICAL SPECIFICATIONS

Specification	Detail
Model	Gold V2 18"
Nominal Impedance	Dual 4 Ohm (D4)
RMS Power Handling (Conservative)	1500 Watts
Maximum Excursion (XMAX)	31MM
Voice Coil	3-inch 4 Layer (25% Longer than V1)
Motor Structure	Triple Stack 220mm Motor with Venting (15% Larger than V1)
Shorting Ring	Aluminum
Spider/Leads	10" Spider Pack with Dual Sewn Leads
Frame/Basket	Cast Aluminum Frame
Terminals	4 Ga Push Terminals
Outside Diameter	18 5/32 Inches
Cutout Diameter	16.93 Inches
Mounting Depth	11.56 Inches
Displacement	0.28 CU FT

RECOMMENDED ENCLOSURE SPECIFICATIONS

Internal Volume (Cubic Ft)	4 - 6 CU FT
Tuning Frequency	28 - 32 HERTZ
Port Area	12 - 16 SQ INCHES OF PORT AREA PER CUBIC FT
Mounting Depth	11.56 INCHES
Cutout Diameter	16.93 INCHES
Displacement	0.28 CU FT
Outside Diameter	18 5/32 INCHES
